The Ultimate XQL Cheat Sheet - 25+ Essential Queries for Cortex XDR

Having a solid library of XQL queries is essential for any Palo Alto Cortex analyst. This cheat sheet provides 25+ queries divided into Dashboard Widget queries (optimized for visualization) and Investigation queries (optimized for threat hunting).

These queries use comp to aggregate data, making them perfect for Pie charts, Bar charts, and dashboards.

1. Top 10 Users with Failed Logins (Bar Chart)

dataset = xdr_data
| filter event_type = "LOGIN" and outcome = "FAILURE"
| comp count(event_id) as failure_count by actor_effective_username
| sort desc failure_count
| limit 10

2. Incident Severity Distribution (Pie Chart)

dataset = incidents
| comp count(incident_id) as total by severity

3. Endpoint OS Distribution (Donut Chart)

dataset = endpoints
| comp count(endpoint_id) as total by os_type

dataset = pan_traffic_raw
| filter action = "deny" and category = "malware"
| comp count(event_id) as blocks by destination_hostname
| sort desc blocks
| limit 10

5. Network Traffic Volume by App (Area Chart)

dataset = pan_traffic_raw
| alter time_bucket = bin(_time, 1h)
| comp sum(bytes_sent + bytes_received) as total_bytes by time_bucket, app

6. Suspicious Powershell Executions over Time (Line Chart)

dataset = xdr_data
| filter actor_process_image_name == "powershell.exe"
| alter time_bucket = bin(_time, 1h)
| comp count(event_id) as executions by time_bucket

dataset = pan_traffic_raw
| filter action = "deny"
| comp count(event_id) as attacks by source_country

dataset = pan_traffic_raw
| comp sum(bytes_sent) as uploads by source_ip
| filter uploads > 1000000000 // 1GB Threshold

dataset = endpoints
| comp count(endpoint_id) as count by endpoint_status

10. Most Common Malware Signatures (Bar Chart)

dataset = xdr_data
| filter event_type = "MALWARE_DETECTED"
| comp count(event_id) as detections by threat_name

Part 2: Normal Search & Investigation Queries

These queries return detailed rows, useful for deep-dive forensic investigations.

11. Find All Executions from USB Drives

dataset = xdr_data
| filter actor_process_image_path contains ":\RECYCLER\" or actor_process_image_path contains "Removable"

12. Locate Specific File Hash across Network

dataset = xdr_data
| filter action_file_sha256 = "your_hash_here"
| fields _time, endpoint_name, actor_process_image_name, action_file_path

13. Trace RDP Connections to Internal IPs

dataset = pan_traffic_raw
| filter destination_port = 3389 and destination_ip_internal = true
| fields _time, source_ip, destination_ip, user

14. Identify "Living off the Land" Binaries (Lolbins)

dataset = xdr_data
| filter actor_process_image_name in ("certutil.exe", "bitsadmin.exe", "mshta.exe")

15. Detect Base64 Commands in PowerShell

dataset = xdr_data
| filter actor_process_image_name == "powershell.exe"
| filter actor_process_command_line contains "-enc" or actor_process_command_line contains "Base64"

16. Search for Newly Created Local Accounts

dataset = xdr_data
| filter event_type = "USER_MANAGEMENT" and action_type = "CREATE"

17. Monitor Modification of Sensitive Registry Keys

dataset = xdr_data
| filter event_type = "REGISTRY"
| filter action_registry_key_name contains "CurrentVersion\Run"

18. Find Suspicious Parent-Child Process Relationships (e.g. Word -> CMD)

dataset = xdr_data
| filter actor_process_image_name == "winword.exe" and action_process_image_name == "cmd.exe"

19. Identify Excessive DNS Queries (Potential Tunneling)

dataset = pan_traffic_raw
| filter destination_port = 53
| comp count(event_id) as dns_queries by source_ip, destination_hostname
| filter dns_queries > 500

20. List Processes listening on non-standard ports

dataset = xdr_data
| filter event_type = "NETWORK" and action_local_port not in (80, 443, 8080)

21. Detect LSASS Memory Dumping

dataset = xdr_data
| filter action_process_image_name == "lsass.exe" and action_type = "OPEN_PROCESS"

22. Find Files Downloaded via Browser then Executed

dataset = xdr_data
| filter actor_process_image_name in ("chrome.exe", "firefox.exe", "msedge.exe")
| filter action_type = "FILE_WRITE"

23. Investigate SSH Logins from External IPs

dataset = xdr_data
| filter event_type = "LOGIN" and auth_method = "ssh" and source_ip_internal = false

24. Audit Admin Activity in the Cloud Console

dataset = cloud_audit_logs
| filter user_role = "Admin" and action_type != "GET"

25. Spot Hidden Files/Directories being Accesses

dataset = xdr_data
| filter action_file_path contains "\." // Unix style hidden
| filter action_file_path contains "$RECYCLE.BIN" // Windows style

Conclusion

Whether you are building a NOC dashboard or hunting for an advanced persistent threat (APT), these queries provide a solid foundation. Remember to always test your queries on a small time range before scaling up to ensure performance!
